Allegro Packets

The network analysis specialist Allegro Packets offers innovative troubleshooting and analysis products to solve network issues with the Allegro Network Multimeter range of appliances. The innovative features of Allegro products meet all requirements for information infrastructures.

Advantages

• High-granular network visibility from Layer 2 to 7 in real time and capture rates up to 240 Gbps / 60 Mpps.
• Extreme performance for up to 400 Gbps network links even in a compact 1U form factor for minimizing your carbon footprint.
• Capture months‘ worth of network traffic data and replay specific timeframes or filtered packets on-demand.
• Very simple installation and setup, with a consistent software platform and intuitive GUI.
• Highly flexible and expandable architecture for seamless upgrades from 1 G to 400 G interfaces and storage expansion.
• Security through two-factor authentication, data-at-rest encryption, and granular user access controls.

For every type of networ; enterprises, data centres, IT service providers, system houses and ISPs, we offer a suitable Network Multimeter:

Portable

500 / 510

Performance

• Average throughput (capture only / full decode): 4 / 2 | 4 / 2.5 Gbit/s
• Average packets per second: 500,000 | 600,000 pps

Physical

• 4 x 10 / 100 / 1000Base-T |
   2 x 2.5G and 2 x 10 / 100 / 1000Base-T Capture Ports
• In-Memory 4 GB / 8 GB | 16 GB
• 1 kg, 148 x 44 x 118 ( W / H / D in mm)

810

Performance

• Average throughput (capture only / full decode): 6 / 3.5 Gbit/s
• Average packets per second (capture only / full decode): 1 Mpps /600 kpps

Physical

• 2 x SFP28 and 3 x 1000Base-T Capture Ports
• In-Memory 16 GB, expandable up to 256 GB
• 2 kg, 254 x 43 x 226 (W / H / D in mm)
• Available also as 1U rack unit

1010 / 3010

Performance

• 2 performance levels available (1010 / 3010)
• Average throughput (capture only / full decode): 20 /10 | 20 / 20 Gbit/s
• Average packets per second (capture only /full decode): 4 / 1.2 Mpps | 4 / 4 Mpps

Physical

• 2 x SFP28 and 3 x 1000Base-T Capture Ports
• In-Memory 16 GB / 64 GB, expandable up to 256 GB
• 2 kg, 254 x 43 x 226 (W / H / D in mm)

x210 series (portable and rackmount)

Performance

• 3 performance levels available (1210 / 3210 / 5210)
• Average throughput (full decode): 12 / 30 / 60 Gbit/s
• Average packets per second (capture only / full decode): 7.5 /3 Mpps | 15 / 6 Mpps | 25 /12 Mpps

Physical

• 4 x SFP+ Capture ports
• 2 regular extension slots for network extension cards
• In-Memory 32 / 96 GB, expandable up to 576 GB 6-8 kg, 436.88 x 44.5 x 429.3 (W / H / D in mm)

Rackmount

x310 series

Performance

• 4 performance levels available (1310 /3310 / 5310 / 7310)
• Average throughput (full decode): 20 /40 / 80 / 120 Gbit/s
• Average packets per second (capture only / full decode): 10 / 4 Mpps | 15 / 7Mpps | 30 / 15 Mpps | 60 / 30 Mpps

Physical

• 2 x SFP+ Capture ports + 3 NICs In-Memory 192 GB, expandable up to 6 TB
• Packet Ring buffer storage configurable with 12 x 2.5“ SATA / U.2 slots
• 20-30 kg, 437 x 43 x 597 (W / H / D in mm)

x410 series

Performance

• 4 performance levels available (1410 /3410 / 5410 / 7410)
• Average throughput (full decode): 20 / 40 / 80 / 120 Gbit/s
• Average packets per second (capture only / full decode): 10 / 4 Mpps | 15 / 7 Mpps | 30 / 15 Mpps | 60 / 30 Mpps

Physical

• 2 x SFP+ Capture ports + 7 NICs
• In-Memory 192 GB, expandable up to 6 TB
• Packet Ring buffer storage configurable with 12 x 3.5“ SATA3 / U.2 slots
• 20-32 kg, 437 x 89 x 648 (W / H / D in mm)

x510 series

Performance

• 4 performance levels available (1510 / 3510 / 5510 / 7510)
• Average throughput and Average packets per second like x410 series
• Completely configurable, 4 NICs (no default capture ports )

Physical

• In-Memory 192 GB, expandable up to 3 TB
• 36 x 3.5" SATA3 / SAS3 slots
• 40-80 kg, 437 x 178 x 699 (W / H / D in mm)

Experience unmatched network visibility and extreme performance.
Accelerate resolution of your critical issues with the most efficient solution on the market.
